Press Release - October 6, 2022

Holt Releases Enhanced Octal ARINC 429 Receiver

Aliso Viejo, CA – Holt Integrated Circuits today announced the release of a new 8-channel ARINC 429 line receiver. The device is an enhanced version of Holt’s well-established HI-35980 (HI-3598) family, with additional features and functionality. The user-programmable label filtering capability has been expanded from 16 labels to all 256 labels, and the 4-word deep receive FIFO has been increased to 32 words deep. In addition, a 32-word deep transmit FIFO has been added, significantly increasing the transmit capability from the single-word buffer on the existing device.

Each receive channel has an integrated line receiver, enabling direct connection to an ARINC 429 bus. The user has the option on each channel to use the built-in input resistor or use an external resister to provide addition flexibility for external lightning protection. The digital transmit channel also has a digital output pin to set the data rate on an external line driver, such as Holt’s lightning-protected HI-8597 or galvanically isolated HI-8598.

“This enhanced device provides our customers with additional functionality and flexibility for data management in ARINC 429 networks,” said George Noh, Director of Sales and Marketing at Holt. “The integration of 8 receive channels in a single compact IC greatly reduces customer component count, size and cost.”

The device is available in industrial −40oC to +85oC and extended −55oC to +125oC temperature ranges with optional burn-in at the higher temperature. Samples are available from Holt on request.

Holt Integrated Circuits today announced the release of a new ARINC 429 Development Kit, ADK-35981. The evaluation board demonstrates the operation of Holt's HI-35981, an Octal ARINC 429 Receiver with Label Recognition and a SPI Interface.

The kit is composed of two boards, a lower processor mother board and an upper HI-35981 demonstration board. The 2-board assembly and C project reference design provides a ready-to-run evaluation platform that demonstrates the basic operation of the device. The kit includes full project software and source files and for convenience, the IAR Systems Embedded Workbench® for ARM and a fully integrated debug interface for the ARM Cortex M3 microcontroller. A version of the demonstration software is pre-programmed into the microcontroller flash and the board is operational right out of the box without installing or running the provided software development tools.

To request information on Holt’s ARINC 429, CAN, MIL-STD-1553 and other product lines, readers should contact Holt at (949) 859-8800, by e-mail at info@holtic.com, or visit the Holt website at www.holtic.com
